Off-The-Road tires
OTR TIRES SPEC SHEET
| Size | PATTERN NO. |
TRA CODE |
Type | PR | Rim | NSD (mm) |
LL/SS |
|---|---|---|---|---|---|---|---|
| 16.00R25 | YB916 | E4 | TT/TL | โ โ โ | 11.25/2.0 | 40.00 | 197B |
| 16.00R29 | YB916 | E3 | TT/TL | โ โ โ | 11.25/2.5 | 38.00 | 200A2/182B |
| 18.00R25 | YB708 | IND-4 | TL | โ โ โ | 13.00/2.5 | 62.00 | 216A5 |
| 18.00R25 | YB910 | L5S | TL | โ โ โ | 13.00/2.5 | 82.00 | 204A2 |
| 14.00R20 | YB016 | TL | 20 | 10.00 | 20.00 | 164/161K | |
| 16.00R20 | YB016 | TT | 18 | 11.25 | 15.00 | 173L | |
| 16.00R20 | YB016 | TT | 18 | 11.25 | 20.50 | 173K | |
| 16.00R20 | YB016 | TL | 22 | 11.25 | 20.50 | 174G | |
| 395/85R20 | YB016 | TL | 16 | 11.00 | 22.50 | 162K | |
| 15.5R20 | YB016 | TL | 20 | 12.00 | 20.00 | 173G | |
| 550/75R21 | YB016 | TT | 18 | 440-533 | 20.00 | 164G | |
| 1300ร530R533 | YB016 | TT | 20 | 440-533 | 20.50 | 170G | |
| 1500ร600R635 | YB016 | TL | 32 | 500-635 | 20.50 | 182G | |
| 1300*530-533 | YB018 | E2 | TT | 20 | 440-533 | 24.00 | 170F |
| 1500*600-635 | YB018 | E2 | TT | 22 | 500-635 | 28.00 | 176G |
| 1025*420-457 | YB019 | E2 | TT | 16 | 330-462 | 16.00 | 149G |
| 13.00R25 | YB912 | E3 | TT | โ โ โ | 10.00/1.5 | 26.00 | 182A2/163B |
| 14.00R24 | YB912 | E3 | TT | โ โ โ | 10.00/2.0 | 26.00 | 188A2/169B |
| 14.00R25 | YB912 | E3 | TT/TL | โ โ โ | 10.00/2.0 | 26.00 | 188A2/169B |
| 16.00R25 | YB912 | E3 | TT/TL | โ โ โ | 11.25/2.0 | 30.00 | 195A2/177B |
| 16.00R25 | YB913 | E3 | TT/TL | โ โ โ | 11.25/2.0 | 30.00 | 195A2/177B |
| 23.5R25 | YB913 | L3 | TL | โ โ | 19.50/2.5 | 35.00 | 201A2 |
| 16.00R25 | YB913+ | E3 | TT/TL | โ โ โ | 11.25/2.0 | 33.00 | 195A2/177B |
| 14.00R25 | YB916 | E3 | TT/TL | โ โ โ | 10.00/2.0 | 28.00 | 188A2/169B |
| 14.00R25 | YB916 | E4 | TT/TL | โ โ โ | 10.00/2.0 | 38.00 | 188A2/169B |
